This is the Mach-1 D3642 high torque digital programmable metal geared high voltage servo. We have spent 18 months testing and developing these servos in compeition race conditions to provide the highest quality servo's that will exceed everyones expectations.
Mach-1 servos deliver on all fronts, quality, performance and value for money.
Our specifications make our servos an excellent choice for any 1/8 or 1/10 scale racer.
Check out these features:
* Light weight engraved aluminiium case design.
* A high quality & very efficient brushless motor.
* Our case is IP 67 rated waterproof.
* Programmable Digital Circuits control the servo.
* Magnetic angle sensors for higher accuracy and longer service life.
* High precision stainless steel gear.
* Fully enclosed ball bearings, increased accuracy and longer life.
* 25T single arm aluminium servo arm.
MACH-1 S-SERIES // 1:8 BRUSHLESS DIGITAL SERVO
MODEL: D3642HBM S SERIES
- Dimensions: 40 × 20 × 37.5 mm (1.575in x 0.7874in x 1.476)
- Weight: 76g (2.68oz)
- Working voltage: 4.8~ 8.4V
- Motor type: Brushless motor
- Potentiometer: Magnetic angle sensor
- Gear type: Strength steel
- Case type: Aluminum alloy
- Waterproof: IP67
- Spline: 25T
- Pulse: 500~2500us
- Working Range: 350°
Stall Torque:
VOLTAGE KG-CM OZ-IN 4.8v 28.0 kg-cm 389 oz-in 6.0v 32.0 kg-cm 444 oz-in 7.4v 37.0 kg-cm 514 oz-in 8.4v 42.0 kg-cm 583 oz-in Operating Speed:
VOLTAGE SEC-60 DEG° 4.8V 0.14 sec/60° 6.0v 0.12 sec/60° 7.4v 0.10 sec/60° 8.4v 0.09 sec/60°
